The 22-Valve Spiral Spray Gun for Coating sets new standards in uniform surface coverage, utilizing multiple synchronized nozzles to create a continuous spiral pattern that eliminates gaps common in traditional spray systems.
Unlike single-nozzle guns that require overlapping passes, this high-performance tool features 22 precision-machined valves arranged in a circular array, delivering a 20-80mm adjustable spray width with consistent 30-100g/m² coating weights. Its robust construction handles high-viscosity coatings up to 10,000 cP, making it suitable for protective, decorative, and functional coatings in industrial manufacturing .
22 individually controlled nozzles create overlapping spiral patterns that achieve 98% surface coverage efficiency, reducing material waste by 25% compared to conventional spray guns .
A precision dial allows stepless adjustment of spiral pitch from 5mm to 25mm, enabling fine-tuning of coating density for different surface textures and porosity levels.
All wetted components are constructed from heat-resistant alloys, supporting coating materials up to 180°C—ideal for thermosetting paints and adhesives requiring elevated application temperatures.
Perfect for applying anti-corrosion coatings to metal pipes, creating uniform coverage even on curved surfaces that challenge traditional spray systems.
Ideal for applying rubberized undercoating to vehicle chassis, delivering consistent thickness that withstands stone impacts and environmental exposure.
Used for applying protective coatings to machinery components, with adjustable spiral patterns accommodating flat, curved, and irregular surfaces.
How to adjust for different coating viscosities?
Use the pressure regulator (2-6 bar) to control flow rate: lower pressure (2-3 bar) for high viscosity materials (>5,000 cP) and higher pressure (4-6 bar) for thinner coatings.
What maintenance prevents nozzle clogging?
Perform daily flushing with appropriate solvent and use the auto-purge function after each shift. Replace nozzle filters every 8 hours when spraying particulate-containing coatings.
Can it handle water-based coatings?
Yes, when equipped with the optional stainless steel fluid path upgrade, it safely dispenses water-based formulations without corrosion issues .
